Diving Board Parts

Details:
SR Smith Item Number FC-100A

U-Frame Diving Board Fulcrum Pad

• Heavy-duty rubber
• 20” long
• Accommodates 1.90” OD tubing

Used On S.R. Smith Diving Boards

Details:
SR Smith Item Number 05-600

Rubber Cap for Diving Board Nut

5/8 Inch
Used On S.R. Smith Diving Boards

Details:
SR Smith Item Number 05-618

Rubber Nut Cap for Diving Board

1/2 Inch
Used On S.R. Smith Diving Boards

Details:
SR Smith Item Number 05-619

Rubber Mounting Washer for Diving Board

1/2 Inch x 2 Inch
Used On S.R. Smith Diving Boards

Details:
SR Smith Item Number 05-632

Plastic Cap for Diving Board Bolt Head

Includes Washer
Used On S.R. Smith Diving Boards

Details:
SR Smith Item Number 67-209-903-SS
Hole Pattern: 12" Center to Center
Bolt Size: 1/2 x 5"
Used On S.R. Smith Diving Boards

• 18” Commercial Board, 10’ and 12’

Details:
SR Smith Item Number 67-209-913-SS
1/2 Inch x 5 Inch SS
Used on S.R. Smith Diving Boards

• Frontier IV Board

Details:
SR Smith Item Number 67-209-904-SS
Used On S.R. Smith Diving Boards

• 20” Commercial Board, 14’ and 16’

Details:
SR Smith Item Number 67-209-909-SS
1/2 Inch x 5-1/2 Inch SS
Used On S.R. Smith Diving Boards

Details:
SR Smith Item Number 67-209-910-SS
1/2 Inch x 5 Inch SS
Used On S.R. Smith Diving Boards

Details:
SR Smith Item Number 67-209-911-SS
1/2 Inch x 4-1/2 Inch SS
Used On S.R. Smith Diving Boards

Details:
SR Smith Item Number 69-209-032-SS
3 Inch SS
Used On S.R. Smith Diving Boards

• Frontier II Board

Details:
SR Smith Item Number 71-209-545
Length: 15"
Width: 2-3/4"
Thickness: 3/4"
Used On S.R. Smith Diving Boards
